Application & Features
Roller is made of chilled alloy cast iron, The surface is high glossy, hard and wearable. Thermal conductive oil or steam is used in the jacket for heating. Durative lubrication is adopted with visual glass display. Overload protection device is equipped to protect the major components. Emergency brake switch can be used to stop the machine if there is any accident accures. Also equipped with high grade gear reducer, the noise is very low when it is running.
Main technical parameters
Type | SK400ｘ1000 | SK450ｘ1200 | SK560ｘ1830 | SK610ｘ2030 | SK660ｘ2300 | SK710ｘ2500 | SK760ｘ2800 | SK810ｘ3000 |
The diameter of the front and rear rollers（mm） | Ø400 | Ø450 | Ø560 | Ø610 | Ø660 | Ø710 | Ø760 | Ø810 |
Roller working length（mm） | 1000 | 1200 | 1830 | 2030 | 2300 | 2500 | 2800 | 3000 |
Main motor power（KW） | 45 | 55 | 75 | 90 | 132 | 185 | 220 | 250 |
Reducer | Hardened reducer | |||||||
Transmission | Universal joint drive | |||||||
