Application & Features
It is used in mixing, stirring, coloring and processing all kinds of material in plastic, rubber, daily chemical articles and other industries. The discharging mode adopts the temperature automatic control and the manual control.
Main technical parameters
Type | SHR-10A | SHR-50A | SHR-100A | SHR-200A | SHR-300A | SHR-500A | SHR-800A | SHR-1000A |
The total volume（L） | 10 | 50 | 100 | 200 | 300 | 500 | 800 | 1000 |
Effective volume（mm） | 7 | 35 | 75 | 150 | 225 | 375 | 600 | 750 |
Motor Power（KW） | 3 | 7/11 | 14/22 | 30/42 | 40/55 | 55/75 | 83/110 | 110/160 |
Weight（KG） | 135 | 600 | 1000 | 1500 | 2300 | 3500 | 5000 | 6500 |
