Application & Features
the machine is suitable for all kinds of transparent, translucent and high filled rigid PVC plastic packaging sheet, printed sheet and plastic sheet production。
Main technical parameters
Type | SY-5L950 | SY-5г1050 | SY-6г1200 | SY-5г1300 | SY-5г1500 | SY-5г1600 | SY-5г1800 |
Roller Specifications | Φ320x950mm | Φ400x1050mm | Φ400x1200mm | Φ450x1300mm | Φ510x1500mm | Φ560x1600mm | Φ610x1800mm |
Arranged in the form of cylindrical roller | L- | Inverted-L | Inverted-L | Inverted-L | Inverted-L | Inverted-L | Inverted-L |
Rolling speed（m/min） | 5-25 | 6-30 | 6-30 | 7-35 | 8-40 | 8-45 | 10-50 |
Roll number (root) | 5 | 5 | 6 | 5 | 5 | 5 | 5 |
Thickness of rolled products（mm） | 0.1-0.6 | 0.06-1.00 | 0.2-1.2 | 0.08-1.00 | 0.08-1.00 | 0.08-1.00 | 0.08-1.00 |
Width rolled products（mm） | 450-770 | 610-820 | 610-950 | 610-1050 | 720-1250 | 720-1350 | 800-1500 |
Drive power（KW） | 45 | 115 | 136 | 170 | 235 | 290 | 380 |
Heating power（KW） | 90 | 210 | 240 | 265 | 315 | 385 | 456 |
Yield（kg/h） | 250 | 450 | 500 | 650 | 800 | 1000 | 1500 |
