Application & Features
This machine mainly uses in the rubber (tires, belts,textile fiber rubberizing and so on),the plastic (thin film, sheet, thin sheet plate, wallpaper, floor and so on.) formation processing
Main technical parameters
Type | XY-4Γ230ｘ630 | XY-4Γ360ｘ1120 | XY-4Γ400ｘ1400 | XY-4Γ450ｘ1500 | XY-4Γ610ｘ1730 | XY-4Γ710ｘ2130 | XY-4Γ810ｘ2430 |
Roll Diameter（mm） | 230 | 360 | 400 | 450 | 610 | 710 | 810 |
The length of the roll surface（mm） | 630 | 1120 | 1400 | 1500 | 1730 | 2130 | 2430 |
Roll ratio | 1:1:1:1 | 0.733:1:1:0.73 | 1:1.383:1.383:1 | 1:1.5:1.51 | 1:1.4:1.4:1.4 1:1.4:1.4:1 | 1:1.5:1.5:1 | 1:1.5:1.5:1 |
The roll speed（m/min） | 2.1-21 | 2-20 | 3-26 | 3-26 | 8-50 | 3-30 | 2-20 |
Pitch Range（mm） | 0-10 | 0-10 | 0-10 | 0-10 | 0-20 | 0-20 | 0.5-25 |
Products minimum thickness（mm） | 0.2 | 0.2 | 0.2 | 0.2 | 0.15 | 0.15 | 0.5 |
Product Width（mm） | 500 | 1000 | 1200 | 1300 | 1500 | 1900 | 2150 |
Motor Power（KW） | 15 | 55 | 75 | 110 | 160 | 185 | 280 |
Weight（KG） | 4800 | 15000 | 18500 | 33000 | 62000 | 100000 | 126000 |
