Application & Features
This equipment possesses temperature and time control system. Accurate and easy to operate. Mixed refine operation could achieve the best result of dispersion and uniformity. Tilting mixing chamber and mechanical shaft sealing designs for easy cleaning and colour changing. Pressure sealed mixing chamber can assure the quality of the mixed material and prevent the environment pollution. The mixing chamber is made of soud alloy steel and the working surface is coated with hard chromium for supper anti-abrasion.
Main technical parameters
Type | NL-10L | NL-20L | NL-35L | NL-55L | NL-75L | NL-110L | NL-150L |
Main motor power（KW） | 22 | 37 | 55 | 75 | 110 | 160 | 220 |
Cylinder diameter（mm） | Ф160 | Ф200 | Ф250 | Ф300 | Ф350 | Ф420 | Ф500 |
Feeding mode (front / back) | Front type | Before and after the investment style/Rear Projection | |||||
Weight（KG） | 2300 | 4200 | 6500 | 8500 | 10600 | 14000 | 20000 |
Mounting dimensions（mm） | 2150ｘ1350ｘ2200 | 2350ｘ1550ｘ2400 | 2570ｘ2180ｘ2570 | 3370ｘ2460ｘ3180 | 3550ｘ2560ｘ3220 | 4245ｘ2950ｘ3380 | 4580ｘ3200ｘ4100 |
